Both @Input and @Output allow specifying a customized name for the channel, as follows:

public interface Barista {
    ...
    @Input("inboundOrders")
    SubscribableChannel orders();
}

In this case, the name of the bound channel being created will be inboundOrders.

For ease of addressing the most common use cases that involve either an input or an output channel, or both, out of the box Spring Cloud Stream provides three predefined interfaces.

Source can be used for applications that have a single outbound channel.

public interface Source {

	String OUTPUT = "output";

	@Output(Source.OUTPUT)
	MessageChannel output();

}

Sink can be used for applications that have a single inbound channel.

public interface Sink {

	String INPUT = "input";

	@Input(Sink.INPUT)
	SubscribableChannel input();

}

Processor can be used for applications that have both an inbound and an outbound channel.

public interface Processor extends Source, Sink {
}

There is no special handling for either of these interfaces in Spring Cloud Stream, besides of the fact that they are provided out of the box.

For each of the bound interfaces, Spring Cloud Stream will generate a bean that implements it, and for which invoking an @Input or @Output annotated method will return the bound channel. For example, the bean in the following example will send a message on the output channel every time its hello method is invoked, using the injected Source bean, and invoking output() to retrieve the target channel.

@Component
public class SendingBean {

    private Source source;

    @Autowired
    public SendingBean(Source source) {
        this.source = source;
    }

    public void sayHello(String name) {
		     source.output().send(MessageBuilder.withPayload(body).build());
	  }
}

Bound channels can be also injected directly. For example:

@Component
public class SendingBean {

    private MessageChannel output;

    @Autowired
    public SendingBean(MessageChannel output) {
        this.output = output;
    }

    public void sayHello(String name) {
		     output.send(MessageBuilder.withPayload(body).build());
	  }
}

Note that if the name of the channel is customized on the declaring annotation, that name should be used instead of the method name. Considering this declaration:

public interface CustomSource {
    ...
    @Output("customOutput")
    MessageChannel output();
}

The channel will be injected as follows:

@Component
public class SendingBean {

    @Autowired
    private MessageChannel output;

    @Autowired @Qualifier("customOutput")
    public SendingBean(MessageChannel output) {
        this.output = output;
    }

    public void sayHello(String name) {
		     customOutput.send(MessageBuilder.withPayload(body).build());
	  }
}

Due to the fact that Spring Cloud Stream is Spring Integration based, it completely inherits its foundation and infrastructure, as well as the component. For example, the output channel of a Source can be attached to a MessageSource, as follows:

@EnableBinding(Source.class)
public class TimerSource {

  @Value("${format}")
  private String format;

  @Bean
  @InboundChannelAdapter(value = Source.OUTPUT, poller = @Poller(fixedDelay = "${fixedDelay}", maxMessagesPerPoll = "1"))
  public MessageSource<String> timerMessageSource() {
    return () -> new GenericMessage<>(new SimpleDateFormat(format).format(new Date()));
  }
}

Or, the channels of a processor can be used in a transformer, as follows:

@EnableBinding(Processor.class)
public class TransformProcessor {
	@Transformer(inputChannel = Processor.INPUT, outputChannel = Processor.OUTPUT)
	public Object transform(String message) {
		return message.toUpper();
	}
}

Complementary to the Spring Integration support, Spring Cloud Stream provides a @StreamListener annotation of its own modeled by the other similar Spring Messaging annotations (e.g. @MessageMapping, @JmsListener, @RabbitListener, etc.). It provides a simpler model for handling inbound messages, especially for dealing with use cases that involve content type management and type coercion. Spring Cloud Stream provides an extensible MessageConverter mechanism for handling data conversion by bound channels and, in this case, for dispatching to @StreamListener annotated methods.

For example, an application that processes external Vote events can be declared as follows:

@EnableBinding(Sink.class)
public class VoteHandler {

  @Autowired
  VotingService votingService;

  @StreamListener(Sink.INPUT)
	public void handle(Vote vote) {
		votingService.record(vote);
	}
}

The distinction between this approach and a Spring Integration @ServiceActivator becomes relevant if one considers an inbound Message with a String payload and a contentType header of application/json. For @StreamListener, the MessageConverter mechanism will use the contentType header to parse the String into a Vote object.

Just as with the other Spring Messaging methods, method arguments can be annotated with @Payload, @Headers and @Header. For methods that return data, @SendTo must be used for specifying the output binding destination for data returned by the methods as follows:

@EnableBinding(Processor.class)
public class TransformProcessor {

  @Autowired
  VotingService votingService;

  @StreamListener(Processor.INPUT)
  @SendTo(Processor.OUTPUT)
	public VoteResult handle(Vote vote) {
		return votingService.record(vote);
	}
}

	Note
	Content type headers can be set by external applications in the case of Rabbit MQ, and they are supported as part of an extended internal protocol by Spring Cloud Stream for any type of transport (even the ones that do not support headers normally, like Kafka).
